Frame depth: 4-7/8” with mullion grooves and integrated nailing fin (optional new construction installation)

Sizes: 3 standard widths (5’, 6’, 8’) with 6’-8” height; custom sizes available

Operation: Single operable sash (left or right-handed)

Performance: High-density internal walls for thermal, structural, and sound insulation

Air tightness: Integrated interlock system on meeting rail to reduce air infiltration

Construction: Fully welded frame and sash for maximum strength

Design: Equal lite configuration

Sash options: Lift function for easy removal, anti-lift insert for added security

Threshold: Anodized aluminum with Q-LON gasket

Screen track: Anodized aluminum

Rollers: Stainless steel track with double tandem concealed steel rollers (adjustable, with steel bearings)

Locking system: 2-point mortise lock with narrow line

Handles: Intuition Handle with semi-automatic operation, keyed outside metal pull handle (powder coated)

Additional security: 2-position foot lock for ventilation and enhanced protection

Screen: Lockable extruded aluminum frame with fiberglass mesh

Glazing: Internal for added security; double or triple glass options

• Door: U-value as low as 0.23 (double), 0.18 (triple)
• Fixed unit: U-value as low as 0.22 (double), 0.16 (triple)

Reinforcement: Galvanized steel inside sash and mullion, encapsulated with insulating chambers

Colors: Solid white or tan, unlimited custom colors with eco-friendly water-based paint

Finishes: “Art-Wood” finishes, powder-coated and metallic handle options

Security: 4-point locking mortise lock

Glass options: Multiple LoE coatings and gas fills

Grids: Decorative internal or external grid options

Accessories: Couplers, brick moldings, nail fin

Screens: Aluminum or pet-resistant mesh

Blinds: Internal blinds for added privacy and convenience

Advanced Window Corp. offers a wide range of exterior and interior color and finish options designed specifically for vinyl doors. High-performance coatings are engineered for durability, heat reflectance, and long-lasting appearance. Waterborne formulations are non-toxic, environmentally friendly, and free from lead and chromates.

The coating is developed for PVC, providing excellent adhesion and elasticity. It moves with the vinyl during temperature changes while maintaining strong resistance to abrasion and impact. Advanced additives help maintain color stability while reducing heat absorption over time.

Laminates
Decorative laminate films undergo comprehensive in-house testing, including heat reflectivity, fade resistance (Delta E), distortion, and adhesion. This process allows Advanced Window Corp. to offer a lifetime warranty on the laminate bond.

Warranty
Advanced Window Corp. provides a 10-year warranty on painted vinyl finishes for exterior and/or interior surfaces.

A variety of colors, finishes, and grid styles are available. Current customization options and combinations can be confirmed with ARDMOR Windows & Doors, an authorized contractor working with Advanced Window Corp., to help select the most suitable solution for each project.

⠀

⠀

Patterned glass, also known as obscured or decorative glass, features textured designs pressed into the surface. These patterns provide privacy while still allowing light to enter. Popular options include frosted, rain, glue chip, and matte finishes.

Tinted glass helps reduce glare and limits fading caused by sunlight. It is often used to enhance exterior appearance while improving comfort indoors. Common tint options include gray and bronze.

Coated glass features an invisible metallic layer that allows natural light to pass through while improving performance. Certain coatings help reflect heat, increase energy efficiency, and make the glass easier to maintain.

Tempered Glass is heated to high temperatures and rapidly cooled, making it up to four times stronger than annealed glass. When broken, it shatters into small, blunt pieces designed to reduce the risk of injury.

Laminated Glass is made by bonding two panes of glass with a clear interlayer. If broken, the glass remains held together, improving safety and helping protect against forced entry.

⠀

⠀

All door products are equipped with insulated glass units (IGUs). IGUs are available in double- or triple-pane configurations and are designed to improve energy efficiency, comfort, and durability.

Each insulated glass unit is covered by a 20-year warranty against seal failure, meeting the highest standards in the fenestration industry. IGU thickness varies by product and configuration, with glass panes available in annealed, heat-treated, tempered, or laminated options. Units can also be customized with low-emissivity (Low-E) coatings, tints, or decorative patterns.

All exterior-facing glass surfaces include a NEAT® protective coating, which helps reduce water spotting and allows for easier, low-maintenance cleaning.

Spacer Systems & Gas Fill use advanced warm-edge spacer technologies to separate glass panes and improve overall performance. Stainless steel and flexible composite spacers help reduce heat transfer, while dry air, argon, or argon-krypton gas fills enhance thermal insulation and sound reduction.

Decorative Options include grids or internal blinds sealed inside the insulated glass unit. These elements add visual interest or functionality while remaining protected from dust and moisture, with no need for cleaning or maintenance.

All insulated glass units are manufactured under strict industry standards and regularly tested to ensure consistent performance and reliability.
Advanced Window Corp. is certified as an insulated glass manufacturer by Keystone Certifications Inc. under the ANSI program for insulated glass unit producers.

⠀

⠀

Grids are available for sliding doors and are sealed inside the insulated glass unit, so they enhance the door’s appearance without affecting cleaning or operation. This design adds visual character while maintaining energy efficiency and low maintenance.

⠀

⠀

Blink® Blinds + Glass is an insulated glass unit with blinds sealed between the panes, designed for doors and glass panels. The system provides a clean, modern alternative to traditional blinds while improving comfort, safety, and ease of use.

Features & Benefits

• No Dusting, Maintenance Free
• Built to Last
• Energy Efficient
• Child and Pet Friendly
• Easy to Use
• 10+ Year Waranty
• Available in 1” or 7/8” Insulated Glass Unit
• Custom sizes
• Tilt Only or Lift and Tilt Options Available

⠀

⠀

⠀

⠀

Door systems are equipped with premium hardware and handle components from globally recognized manufacturers, including ROTO Frank, AmesburyTruth, Interlock USA, and Emtek.

These components ensure smooth and reliable operation, enhanced security, and long-term durability, while offering refined aesthetics and a choice of handle styles designed specifically for modern sliding doors.

The hardware is engineered to meet high performance standards and deliver consistent, comfortable everyday use.

⠀

⠀

Insect Screens are included with all operable products. Depending on the product type and configuration, screens may be fixed or operable, while always remaining fully removable.

Partial and full-screen options are available, along with an elegant self-retracting screen system for select products.

Screens are built with durable extruded aluminum frames for long-lasting performance and are color-matched to the product for a clean, cohesive appearance.

Screen Mesh Options include standard fiberglass mesh in charcoal or gray, low-visibility BetterVue® fiberglass mesh with Water Shed technology for clearer views and easier cleaning, and PetScreen® designed for added durability. Aluminum mesh is also available in bright or black finishes.

⠀

⠀

Natural Light: Maximizes light, perfect for compact spaces

Durability: Weather-resistant, strong, and secure construction

Energy Efficiency: Exceeds the latest Energy Star ratings

Glass Options: Reinforced mullions support large glass openings with side panels or transoms

Design: Modern engineering with both functionality and elegance

Longevity: Built for long-lasting performance with high-quality materials

Top Warranty: One of the industry’s best warranties

Premium Materials: Manufactured with the highest quality materials

Made in the USA: Crafted in the USA with precision and care

Energy Star Partner: Meets the highest energy efficiency standards

Partnership with ARDMOR Windows & Doors: Direct partnership ensures competitive pricing and strict installation standards

⠀

⠀
